SPECIFICATIONS:             RP10 ELECTRICAL                 Linear taper(B) other taper                                            MAXIMUM WORKING VOLTAGE：       200V DC     100V DC                              RATED WATTAGE ：                0.15 W       0.07W                    NOISE ：                        Less than 47Mv OPERATING TEMPERATURE：        -25°C ~+70 °C CONTACT RESISTANCE：            Less than 5% RESIDUL RESISTANCE：            Term.1~2:Less than 3Ω                                 Term.2~3:Less than 3Ω MECHANICAL TOTAL ROTATION ANGLE：          235°±10° ROTATIONAL TORQUE：             0.4~2.0 Ncm STOPING OPERATING   TORQUE FORCE：                  5 Ncm Max： LIFE TEST：                     500 Cycles, (LL)10,000 Cycles
