| Series | PW 70 |
| Max. active angle | 360° |
| Stops at max. | 350° |
| Resistance on angle limited by stops |
min.50Ω max.50KΩ |
| Resistance tolerance | ±5% |
| linearity tolerance | ±0.2 up to 0.15% |
| resolution | 0.3 up to <0.1% |
| capacity | 6W |
| multiple design | six fold |
| functional winding | · |
| oilfilling | · |
| limit swichtes | versin M...only |
| temperature coefficient | 17 ppm |
| constricted resistance and linearity tolerances possible | |
