| Series | PW 45 |
| Max. active angle | 360° |
| Stops at max. | 345° |
| Resistance on angle limited by stops |
min.25Ω max.20KΩ |
| Resistance tolerance | ±5% |
| linearity tolerance | ±0.3 up to 0.2% |
| resolution | 0.5 up to <0.1% |
| capacity | 2.5W |
| multiple design | two fold |
| functional winding | · |
| oilfilling | · |
| temperature coefficient | 17 ppm |
| constricted resistance and linearity tolerances possible | |
