ROTATION ANGLE
ROTATION TORQUE
SHAFT STOP STRENGTH
CLICK TORQUE |
300°±5°
20~200gf.cm
more than 3 kgf.com/min
50~300 gf.cm |
RATED WATTAGE
RATED VOLTAGE
INSULATION RESISTANCE
DIELECTRIC
ROTATION LIFE |
linear
taper(B) Other taper
0.08W 0.04W
150V 100V
50MΩ DC500V
AC500V minute
15,000 cycles |
